Direct Acting Solenoid Valves K0200HAXR
- Single 3/2 with spring return
- 1/8” & ¼” port options
- AC & DC solenoid coil options
- Weather-Proof options are IP65 rated
- Explosion-Proof options are CSA & FM approved and ATEX Compliant
K0200HAXR
$18.00
Quantity
Estimated Ship Date: 11/04/2025
*Estimated Ship Date based on standard manufacturing times for quantities of 10 or less. Shipments will be made anywhere in the United States.
Product Information
| Valve Series | K02 |
| Valve Function | Single Direct Solenoid 3/2 Normally Open |
| Actuation | Electrical |
| Port Size | 1/8" |
| Port Thread | NPT |
| Body Type | Base Mount |
| Return Type | Spring Return |
| Construction | Poppet |
| Flow | 0.1 Cv (100 l/min) |
| Manual Override | Push Non-Locking |
| Application | Standard |
| Ambient Temperature | -18 to 50 C (0 to 123 F) |
| Operating Pressure | Vacuum to 150 psig (1.0 to 10.3 l/min) |
| Body Material | Aluminum |
| Seal Material | Buna-N |
+
Direct Acting Solenoid Valves
K0200HAXR
Contact Us for a 3D Model
+
Direct Acting Solenoid Valves
K0200HAXR
Contact Automatic Valve for Ordering Information
+
